Description
Sturdy, frost-free and weather resistant keypad with 2 integrated relays.
The new SlimStone-2 keyboard features two relays for better access control and greater flexibility. It allows you to control 2 different automation devices or open the gate in 2 different ways. This keypad with integrated LED backlight is unique due to its robustness and extreme weather resistance (IP68). Access control is guaranteed in all weather conditions. The two integrated relays with “Fail Open” and “Fail Close” contacts make it easy to connect Locinox and other manufacturers’ automation products.
Specifications:
- IP68-rated – extremely water and dust resistant
- Vandal-resistant aluminium body with scratch-resistant textured lacquer
- Energy-saving dimmable white LED bulbs
- Highly resistant stainless steel buttons tested to 1,000,000 clicks or more
- Easy installation and configuration
- Easy programming of up to 100 user codes
- No freezing due to intelligent heating
- Tested from -30 to +85° Celsius
- Adjustable time interval between pulse and timer mode (100 ms – 99 s)
- Operating voltage keypad from 10 to 26 V AC/DC
- Current: 1.0 A (with heating)
- 2 integrated switching relays: 2 x NO – 2 x NC – 2 x COM (max. 2A, 60 W, 26 V AC/DC)
- 2 m connecting cable included
- Consumption: 1.5 W (> 5 °C) + 12 W at maximum heating (< -25 °C)
